Suitable for standardized batch processing, engineering furniture production
High-definition touch screen control
Saw car moving with rack and pinion drive, smooth and reliable;
The main saw adopts synchronous belt drive, which greatly reduces the loss of motor horsepower;
Clamping mechanism with double gripper manipulator, stable structure, can avoid panel scratches, can cut batch narrow strip material at the same time.
|
Model (Model） |
ZD327 |
|
Maximum processing size |
2600x2600mm |
|
Step-in speed of saw car |
3-80m/min |
|
Feeding speed |
0-85m/min |
|
Diameter of main saw blade |
Φ350mm |
|
Extended height of main saw |
80mm |
|
Main saw motor power |
15kw |
|
Main saw shaft speed |
4600r/min |
|
Main saw blade shaft diameter |
30mm |
|
Auxiliary saw blade diameter |
180mm |
|
Auxiliary saw motor power |
1.5kw |
|
Auxiliary saw shaft speed |
7200r/min |
|
Auxiliary saw blade shaft diameter |
30mm |
|
Traction motor power |
1.5kw |
|
Feeding servo motor power |
1.3kw |
|
Working air pressure |
0.6Mpa |
|
Table height |
960mm |
|
Overall dimension approx. |
5400x5300x1720mm |
|
Weight approx. |
4800kg |
Note: The product is constantly improved, when the shape and parameters change, the actual sample shall prevail.
Keywords: computer numerical control panel saw
